A professional sliding table saw designed for rip and cross-cutting of high-density boards, MDF, fiberboard, chipboard, ABS, PVC panels, Acrylic panels, glued panels, solid wood and other wood-based materials of similar structure and hardness. Equipped with powerful main and scoring saw motors, it makes easy work of cutting.
The movable work table is made of strengthened aluminium and guided on strengthened bars. The table is very durable and has a robust, solid and compact structure that ensures comfort and failure-free operations. The machine is ideal for professionals and novices.
|Dimension of sliding table||3200mm*375mm|
|Width of cut||1250mm|
|Maximum height of cut 90°/45°||80/55mm|
|Main saw motor power||5.5KW (7.5Hp)|
|Scoring saw motor power||0.75KW (1.0Hp)|
|Maximum main saw blade size||305mm*30mm|
|Scoring saw blade size||120mm*20mm|
|Blade Tilting / Height Adjustment||Manual/Manual|
|Speed of main saw spindle||4000/5000rpm|
|Speed of scoring saw blade||8800rpm|
|Dust collection outlet||100mm|
